FITZ SRAM GX Eagle AXS Transmission Bike

Build your Fitz

Trail

Build Your Fitz
Fitz
FITZ SRAM GX Eagle AXS Transmission Bike

A balanced take on FITZ, built around proven performance and modern trail capability. FOX Performance 36 SL suspension, SRAM GX Transmission, and Industry Nine 1/1 Trail S wheels deliver the same composed ride FITZ is known for—without unnecessary complexity.

Bike image may not reflect actual build selections

Trail

Build Your Fitz
Fitz
FITZ SRAM GX Eagle AXS Transmission Bike

A balanced take on FITZ, built around proven performance and modern trail capability. FOX Performance 36 SL suspension, SRAM GX Transmission, and Industry Nine 1/1 Trail S wheels deliver the same composed ride FITZ is known for—without unnecessary complexity.

  • SRAM GX Eagle transmission
  • Carbon 140mm frame
  • Industry Nine 1/1 Trail S Wheels

Your build highlights

These components are required:

Your total:

Your total:

Proven, Without Pretense

SRAM GX Transmission brings the same direct, confident shifting found across the Transmission lineup in a package designed for consistent trail use. It’s precise, durable, and easy to trust—an ideal match for riders who value performance that shows up every ride.

Spec’d For The A-Line

FOX Performance 36 SL suspension delivers composed, predictable control across a wide range of terrain, pairing sensitivity with support where it matters most. Combined with Industry Nine 1/1 Trail S wheels, the setup keeps FITZ confident and capable from long climbs to technical descents.
  • FITZ SRAM GX Eagle AXS Transmission Bike
  • FITZ SRAM GX Eagle AXS Transmission Bike

The specs below reflect the default Build Kit and do not account for customizations made in the Bike Builder. See your Build Summary above for custom choices.

Fork Fox Performance 36 SL Grip 140
Front derailleur -
Rear derailleur SRAM GX Eagle Transmission
Shift levers SRAM AXS Pod
Cassette SRAM 1275 GX Eagle Transmission 10-52
Chain SRAM GX Transmission Flat Top
Crankset SRAM GX Transmission 32
Bottom bracket SRAM Dub 73 BSA
Brakes SRAM Motive Bronze 4 Piston 180 Front / 180 Rear
Handlebar OneUp Alloy
Handlebar tape OneUp Lock-On
Stem OneUp
Saddle Selle Italia Model X
Seatpost OneUp Dropper
Wheelset Industry Nine 1/1 Trail S
Tires Continental Magnotal Grip Trail 29x2.4
Geometry

With a long reach and a slack 64.5° head tube angle, FITZ is built for stability without sacrificing agility. The geometry keeps the bike composed at speed and confident through technical terrain, delivering control you can trust as conditions change.

All units are in Millimeters or Degrees
SM MD LG XL
a Stack 610.7 619.7 633.3 646.8
b Reach 430 455 480 505
c Effective top tube 575 603 632 660
d Seat tube length 380 410 430 460
e Head tube length 95 105 120 135
f Head tube angle 64.5° 64.5° 64.5° 64.5°
g Seat tube angle 76.6° 76.6° 76.5° 76.5°
h Bottom bracket drop 35 35 35 35
i Chainstay length 440 440 440 440
k Wheelbase 1193 1223 1254 1286
l Standover height 797.2 814.6 832.4 854.9
n Front center 753.3 782.6 814.1 845.5
o Wheel size 29 29 29 29
Size Guide

This chart offers a general size recommendation based on height. Since fit is personal, our team can help dial in the right size using your measurements and current bike geometry. Contact us at support@alliedcycleworks.com for a custom fit recommendation.

Small Reach: 430mm
157cm 5'2" - 167cm 5'7"
Medium Reach: 455mm
162cm 5'6" - 177cm 5'10"
Large Reach: 480mm
172cm 5'9" - 188cm 6'0"
X-Large Reach: 505mm
180cm 5'11" - 195cm 6'5"
